7530 75x75x30mm dc blower fan dc 5v 12v 24v dc blower fan ball bearing blower fan
DC Brushless blower
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HB7530L05 | 5 | 4.0～5.75 | 0.3 | 2000 | 0.19 | 6.7 | 5.2 | 0.2 | 24.2 |
| HB7530M05 | 5 | 4.0～5.75 | 0.4 | 3000 | 0.31 | 11.1 | 14.3 | 0.56 | 34.3 |
| HB7530H05 | 5 | 4.0～5.75 | 0.6 | 3800 | 0.37 | 13.1 | 23.1 | 0.91 | 42.7 |
| HB7530L12 | 12 | 7.0～13.8 | 0.14 | 2000 | 0.19 | 6.7 | 5.2 | 0.2 | 24.2 |
| HB7530M12 | 12 | 7.0～13.8 | 0.21 | 3000 | 0.31 | 11.1 | 14.3 | 0.56 | 34.3 |
| HB7530H12 | 12 | 7.0～13.8 | 0.4 | 3800 | 0.37 | 13.1 | 23.1 | 0.91 | 42.7 |
| HB7530U12 | 12 | 7.0～13.8 | 0.6 | 4500 | 0.4 | 14.2 | 29.5 | 1.16 | 45.5 |
| HB7530L24 | 24 | 14.0～27.6 | 0.09 | 2000 | 0.19 | 6.7 | 5.2 | 0.2 | 24.2 |
| HB7530M24 | 24 | 14.0～27.6 | 0.14 | 3000 | 0.31 | 11.1 | 14.3 | 0.56 | 34.3 |
| HB7530H24 | 24 | 14.0～27.6 | 0.2 | 3800 | 0.37 | 13.1 | 23.1 | 0.91 | 42.7 |
| HB7530U24 | 24 | 14.0～27.6 | 0.3 | 4500 | 0.4 | 14.2 | 29.5 | 1.16 | 45.5 |
| HB7530L48 | 48 | 28.0～56.0 | 0.06 | 2000 | 0.19 | 6.7 | 5.2 | 0.2 | 24.2 |
| HB7530M48 | 48 | 28.0～56.0 | 0.09 | 3000 | 0.31 | 11.1 | 14.3 | 0.56 | 34.3 |
| HB7530H48 | 48 | 28.0～56.0 | 0.13 | 3800 | 0.37 | 13.1 | 23.1 | 0.91 | 42.7 |
| HB7530U48 | 48 | 28.0～56.0 | 0.18 | 4500 | 0.4 | 14.2 | 29.5 | 1.16 | 45.5 |
