9220 99x95x28mm dc blower fan dc 5v 12v 24v dc blower fan ball bearing blower fan
DC Brushless blower
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HB9220L12 | 12 | 7.0～13.8 | 0.18 | 2700 | 0.32 | 11.2 | 13.2 | 0.52 | 40.3 |
| HB9220M12 | 12 | 7.0～13.8 | 0.32 | 3200 | 0.38 | 13.5 | 19.6 | 0.77 | 45.5 |
| HB9220H12 | 12 | 7.0～13.8 | 0.5 | 3800 | 0.45 | 15.8 | 29 | 1.14 | 48.8 |
| HB9220U12 | 12 | 7.0～13.8 | 0.8 | 4500 | 0.53 | 18.7 | 39.5 | 1.56 | 54.6 |
| HB9220L24 | 24 | 14.0～27.6 | 0.1 | 2700 | 0.32 | 11.2 | 13.2 | 0.52 | 40.3 |
| HB9220M24 | 24 | 14.0～27.6 | 0.18 | 3200 | 0.38 | 13.5 | 19.6 | 0.77 | 45.5 |
| HB9220H24 | 24 | 14.0～27.6 | 0.3 | 3800 | 0.45 | 15.8 | 29 | 1.14 | 48.8 |
| HB9220U24 | 24 | 14.0～27.6 | 0.5 | 4500 | 0.53 | 18.7 | 39.5 | 1.56 | 54.6 |
| HB9220L48 | 48 | 28.0～56.0 | 0.06 | 2700 | 0.32 | 11.2 | 13.2 | 0.52 | 40.3 |
| HB9220M48 | 48 | 28.0～56.0 | 0.1 | 3200 | 0.38 | 13.5 | 19.6 | 0.77 | 45.5 |
| HB9220H48 | 48 | 28.0～56.0 | 0.18 | 3800 | 0.45 | 15.8 | 29 | 1.14 | 48.8 |
| HB9220U48 | 48 | 28.0～56.0 | 0.3 | 4500 | 0.53 | 18.7 | 39.5 | 1.56 | 54.6 |
