RV refrigerator fan
6010 60x60x10mm dc 5v 12v 24v dc axial fan ball bearing cooling fan
DC Brushless fan 60mm fans for rv refrigerators waterproof fan IP55/ ip68
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HD6010L05 | 5 | 4.0～5.75 | 0.21 | 3000 | 0.3 | 10.5 | 1.6 | 0.06 | 22.5 |
| HD6010M05 | 5 | 4.0～5.75 | 0.35 | 4000 | 0.4 | 14 | 2.8 | 0.11 | 29 |
| HD6010L12 | 12 | 7.0～13.8 |
0.13 | 3000 | 0.3 | 10.5 | 1.6 | 0.06 | 22.5 |
| HD6010M12 | 12 | 7.0～13.8 |
0.18 | 4000 | 0.4 | 14 | 2.8 | 0.11 | 29 |
| HD6010H12 | 12 | 7.0～13.8 |
0.23 | 5000 | 0.5 | 17.5 | 4.4 | 0.17 | 34 |
| HD6010L24 | 24 | 14.0～27.6 | 0.06 | 3000 | 0.3 | 10.5 | 1.6 | 0.06 | 22.5 |
| HD6010M24 | 24 | 14.0～27.6 | 0.09 | 4000 | 0.4 | 14 | 2.8 | 0.11 | 29 |
| HD6010H24 | 24 | 14.0～27.6 | 0.13 | 5000 | 0.5 | 17.5 | 4.4 | 0.17 | 34 |
